Product Details
The HD version of the T-Motor F7 Flight Controller is specially designed to work directly with the DJI HD FPV System without soldering. Plug-and-play with the DJI HD System has never been easier!
Specifications
- Brand name: T-motor
- Item name: F7 HD Flight Controller
- MCU: STMF722RET6
- Gyro: MPU6000/BMI270 depending on supply
- RAM: on board 16Mb
- Input Voltage: 12V-25-2V (3-6S)
- BEC: 5V/2A(Receiver), 10V/2A(VTX)
- Dimensions: 37mm x 37mm
- Mounting Holes: 30.5mm x 30.5mm
- Firmware Target: TMOTORF7 (Betaflight)
- Weight: 8.4g
Includes
- 1 x T-Motor F7 HD Flight Controller
- 2 x FC to ESC Cable
- 4 x Vibration Dampeners
