Product Details
This is the top of the range 4in1 ESC from Spedix. If you were a fan of the GS40, the GS45 is a worthy replacement. This ESC is designed to handle all the abuse you can trow at it with the bigger heatsink which helps with cooling and protection.
Key Features
- 2-6S compatible, 45A Continuous output (55A Peak)
- Bat or 10V output to power other gear
- BLheli32 with ESC telemetry support and Current sensor.
- Super low profile (1.6mm with heatsync)
- Delicate parts moved far away from standoff mounting holes for better protection
- Silicone ring inserts can insulate standoffs and ESC, and prevent impact of standoffs on PCB and electronic parts during crash.
- Smaller square footprint with motor connectors compatible with just about any frame out there.
- Includes 3 cables to fit various flight controller amongst other accessories.
Specifications
- Input:3-6 Cell LiPo
- Continuous Current: 45A
- Burst Current: 55A≤10S
- BEC:10V/2A
- Current Detection: Yes
- Firmware: BLHeli_32
- Dimensions: 40.5x42x6.5mm
- Mount holes: 30.5x30.5mm
- Diameter of Mount holes: 3mm
- Weight：17g"
