Product Details
The Merica line of frames comes with no canopy by default. You need to purchase or 3D print one to go along with your frame.
SPECS:
- 69 grams (with canopy and fasteners)
- Carbon Fiber: Twill Weave 3K Matte
- Canopy Material: TPU (multiple colors available - sold separate)
- Standard CF Arm Thickness: 5mm
- Top CF Sandwich Plate: 3mm
- Bottom CF Sandwich Plate: 2mm
- Frame Type: True X (with staggered arms front to rear)
- Frame Size: 204mm
- Camera Angle Range: 10 - 75 degrees
- Motors supported: 22xx, 23xx, 24xx or similar
- Lipos supported: 3s, 4s, 5s, 6s
- Lipo mounting position: Bottom
- Prop Size: 5 inch or (5.5" with some canopies)
- Fastener Material: Aircraft Grade 7075
- Fastener Color: Black
- Ideal ESC: 4-in-1 design with 30.5mm x 30.5mm M3 mounting holes
- Ideal FC: 30.5mm x 30.5mm M3 mounting holes
- Motor pad mounting holes: M3 screws on 16mm or 19mm mounting circles
- Supported FPV Cameras: Runcam Micro Eagle, Runcam Micro Swift 2, Foxeer Predator Micro, Foxeer Micro Monster, Runcam Micro Sparrow 2, or similar
- TPU canopy NOT INCLUDED - You will need to buy or print one separately!
