Product Details
This new version of the popular Mamba F405 mini stack has been updated to include new tweaks such as better interference rejection, larger soldering pad area and a TVS high voltage protection. This is the Mamba basic offers a great bang for the buck when it comes to your flight stack.
FC Specifications
- MCU: 168MHz STM32F405
- IMU: BMI270 or ICM42688P
- OSD: BF OSD AT7456E
- Blacbox: 16M Flash Memory
- Barometer: Yes
- Uarts: 6Set
- Receiver compatibility: TBS/SBUS/IBUS/DSM
- I2C: Yes
- F.Port: Yes
- Buzzer Pad: Yes
- CURR Pad: Yes
- ESC Outputs: 6x
- BEC 3.3V: 0.5A
- BEC 5V: 2.5A
- BEC 9V: 2A
- MB LED: Yes
- BF LED: Yes
- Air Unit Port: Yes
- VTX Switch: Yes
- BEC Protection: Yes
- Receiver Protection: Yes
- TVS Protection: Yes
- Input: 6S Lipo
- Firmware: Betaflight
- Mounting: 20×20mm / M2 or M3
- Size 29×29.5×6.5mm
- Weight: 6g
ESC Specifications
MAMBA F40_BLS MINI
INPUT VOLTAGE: 2~6S Lipo (8.4V~25V)
CONTINUE CURRENT: 40A×4
BURST CURRENT: 45A (10S)
BEC: No
Target：
BLHeli_S CH40
SOFT: Dshot300/600
TVS Protection: Yes
MOUNTING: 20mm, M3/M2
Supply
High-Frequency 470uF/35V ×1
8pin sh1.0 ×2
16AWG 60mm ×2
AMASS Original XT60
