Product Details
Factory Setup Files, Pinouts and Wiring Guides
Iflight have provided all of their factory dumps, along with frame assembly, and electronics wiring guides on their google drive folder
Specifications
ProTek R25 BNF Specs:
*Motor: XING 1404 4600KV (LINK)
*Weight: 147.5g (without battery)
*Bottom plate thickness: 2.5mm
*Top plate thickness: 1.5mm
*Body Size: 143mm*158mm
*FC pattern: 25.5*25.5mm
*FPV cam spacing: 14mm
*Whoop F4 AIO 1.1(LINK)
*Propeller size: 2.5 inch
*Arm Thickness: 2.5mm
*Wheelbase: 113mm
AIO//Whoop AIO F4 V1.1 AIO
Mounting pattern: 25.5*25.5mm/φ3mm
Firmware Target: IFLIGHT_F411_PRO
Constant current: 20A，25A (Burst)
Config：IFLIGHT_F411_PRO.config
Connector: Micro-USB
ESC Firmware: Q-H-15
Current sensor: yes
BEC output: 5V 2A
ESC Telemetry: NO
Size: 30.5*30.5mm
MCU: STM32F411
BLHeli: BLHeli-S
Barometer: NO
Blackbox: 8MB
Gyro: BMI270
INA pad: nR2
Weight: 7.4g
Input: 2-4S
Included
- 1 x ProTek R25 AnalogBNF
- 1 x iFlight Lipo Strap 15*180mm (Color May Vary)
- 2 x Nazgul 2525 propeller (Set of 4 - Color May Vary)
