Product Details
HGLRC SPECTER 1003 18000KV Brushless Motor
Get ready to redefine "small but mighty" with the HGLRC SPECTER 1003 18000KV brushless motor , a pint-sized powerhouse engineered for 75mm tiny drones and toothpick builds. Designed with cutting-edge materials and precision tuning, this motor delivers high torque, responsive handling, and reliable efficiency—all while keeping the heat and weight down.
Whether you're weaving through tight spaces or pushing throttle punches, the SPECTER 1003 doesn't flinch. Featuring a 7075 aviation aluminum rotor, a low-loss stator, and custom N52H curved magnetic steel, this motor isn't just built; it's forged for performance. The 200° heat-resistant copper winding ensures stability in high-stress conditions, while optimized tuning provides smooth power delivery even during rapid throttle shifts.
If you're chasing agility, durability, and an unbeatable power-to-weight ratio, the HGLRC SPECTER 1003 might just be your next obsession.
Key Features:
- Redesigned Rotor: Anodized two-tone finish for durability and style.
- Durable Build: One-piece rotor crafted from 7075 aviation-grade aluminum.
- Enhanced Magnetism: Customized N52H curved magnetic steel for high torque.
- Heat Resistance: Copper winding rated to withstand up to 200°C for smooth performance.
- Optimized Tuning: Linear power output and rapid response to throttle changes.
- Efficient Stator: Made with imported Kawasaki silicon steel to reduce heat and improve efficiency.
- Lightweight Design: Alloy steel outlet shaft minimizes weight without compromising strength.
Specifications:
- KV Rating: 18000KV
- Slot/Pole: 9N12P
- Max Continuous Current: 11.5A
- Max Power: 85W
- Input Voltage: 1-2S LiPo
- Recommended ESC: ≥5A
- Propeller Compatibility: 1.6-2 inches
- Dimensions: Φ13.7mm x 9.2mm
- Mounting Hole: 3 x M1.4-∅6.6
- Weight: 3.35g (with wires)
- Wire Length: 45mm
What's in the Box:
- 1x HGLRC SPECTER 1003 18000KV Brushless Motor
- 4x M1.4 Screws
Disclaimer: Accessories may vary depending on supply. Be sure to check your package contents upon receipt.
