GEPRC Vapor-D5 HD O4 Pro - The Ultimate 5-Inch Freestyle & Cinematic FPV Drone
Looking for a high-performance, HD-ready 5-inch drone that balances power, precision, and cinematic clarity? Meet the GEPRC Vapor-D5 HD O4 Pro, a next-generation FPV machine designed to dominate freestyle, long-range exploration, and cinematic FPV filming. With support for the DJI O4 HD digital system, this quad offers crystal-clear video, ultra-low latency, and buttery-smooth flights.
Why Choose the Vapor-D5 HD O4 Pro?
- Includes DJI O4 Pro HD Video – Unlock 4K/120fps digital clarity with rock-solid long-range performance.
- Powerful Freestyle Performance – Features a balanced low-center-of-gravity frame for ultimate agility and smooth flight control.
- Lightweight, Durable Carbon Fiber Frame – Built to withstand crashes while maintaining a featherlight feel.
- 5-Inch Prop Setup – Ideal for freestyle pilots who demand powerful thrust, sharp cornering, and responsive control.
- Multiple Receiver Options – Available in PNP (for custom receiver setups) or ELRS 2.4G (for long-range, low-latency control).
- Cinematic & Freestyle Ready – Whether you're capturing stunning aerial shots or pulling off mid-air tricks, this drone delivers.
Specifications:
- Model: Vapor-D5 O4 Pro
- Frame: GEP-Vapor-D5 O4 Pro frame
- Wheelbase: 230 mm
- Top Plate: 2.0 mm
- Middle Plate: 2.0 mm
- Bottom Plate: 2.5 mm
- Arm Thickness: 5.0 mm
- FC: GEP-F722-HD v2
- MCU: STM32F722
- Gyro: ICM42688-P (SPI)
- Barometer: Yes
- OSD: Betaflight OSD w/AT7456E
- ESC: TAKER H60_BLS 60A 4IN1 ESC
- VTX: DJI O4 Air Unit Pro
- Camera: O4 Pro Camera
- Antenna: O4 Pro original antenna
- Connector: XT60
- Optional GPS: GEP-M10 GPS
- 5-inch Motor: GEPRC SPEEDX2 2207E 1960 KV
- 5-inch Propeller: GEMFAN 5136
- Vapor-D5 O4 Pro PNP Version Weight: 428 g ±5g
- Receiver: PNP / GEPRC ELRS24 / TBS Nano RX
- Recommended Battery: 6S LiPo 1300mAh – 1800mAh
- Flight Time: 14–19 min
What's in the Box?
- 1 x Vapor-D5 O4 Pro
- 2 x GEMFAN 5136
- 2 x Battery anti-slip pads
- 1 x Spare screw pack
- 1 x Vapor side panel
- 2 x M20×250mm battery straps
- 1 x L-shaped screwdriver 1.5mm
- 1 x L-shaped screwdriver 2.0mm
- 1 x GoPro mount
- 6 x M3×10mm round head screws
- 6 x M3×8mm round head screws
- 2 x M3×6mm flat head screws
- 1 x M5×28mm thin head screw
- 1 x M5 flange nut
- 4 x M3 rivet nuts
Disclaimer: Included accessories may vary depending on stock availability.
