Product Details
Features
- 128M Flash Memory Blackbox
- 480MHz STM32H743 MCU
- Option between MPU 6 Series Dual Gyro or BMI270 Gyro
- LED Controller
- Barometer
- 8 UARTs
Specifications
- LED Controller:BF LED/MB LED (4 Set 2812 LED)
- BEC:3.3V 0.5A& 5V 3A (System Power)
- GYRO: MPU 6 Series DUAL or BMI270 (depending on option selection)
- Input: 3~6S Lipo (12.6~25.2V)
- ESC Soft: Dshot300/600/1200
- Blacbox: 128M Flash Memory
- MCU: 480MHz STM32H743
- MOUNTING: 30.5mm,M3
- 5V 3A(LED)& 9V 3A
- TVS Protection: Yes
- ESC Telemetry: Yes
- ESC Signal: 8 Set
- Power Led: Yes
- Barometer: Yes
- F.Port: Yes
- OSD: Yes
- Buzz: Yes
- Uarts: 8
- I2C:Yes
Includes
- 1x Diatone Mamba Basic MK4 H743 X8 Flight Controller
