Product Details
The OCP 5.8 is our new everyday omni antenna. Proven design, great signal, durable and look amazing. Available in all popular connector configurations.
Features
- Durable poly-carbonate, Injection Molded, ultra-sonically welded Housing
- Clear indication of polarization direction
- Excellent axial ratio and efficiency
- Flexible coax cable option that deflect impacts
- Knurled True-SMA for easy tightening
- Quality MMCX/90 that snap on DJI fpv securely
Specification
- Gain: 1.6dBic
- Cross-Polar Rejection : -10 to -20dB, (3.2%)
- Bandwidth: 5.6GHz-6.0GHz
- Radiation Efficiency: 98%
- SWR: <=1.2:1
- Weight: Vary with connector/cable option
- Dimensions(head): 16.5mm dia. x 10.7mm height.
- Length: Vary with cable option
- Cable: TrueRC RG316S/RG402/RG178 coax
- Connector: Reinforced True-SMA/90 male, U.FL, MMCX/90
Included
- 1x OCP antenna
