Product Details
TBS UNIFY PRO32 DP (MMCX): The Lightweight Heavyweight of Video Transmitters
The TBS UNIFY PRO32 DP (MMCX) is a high-quality video transmitter (VTx) designed specifically for FPV drones. It combines improved robustness, decreased size, and lower power consumption with enhanced performance and durability, thanks to advanced heat dissipation technology that requires no additional heatsink or fan.
Highlights
- World's Lightest 3 Watt Video Transmitter: Weighing in at just 8.7g.
- Frequency Range: 4990 MHz - 6030 MHz.
- OSD Configuration: Utilize TBS Smart Audio 2.1 via Betaflight, TBS Crossfire / Tracer, or Ardupilot.
- One Button Frequency and Power Setup: Simplify your FPV setup.
- LUA Support: For CRSF users.
- MMCX Connector: Reliable and easy to use.
- 2-6S Input: Versatile power options.
- Double Noise Filtering: Over 63dB SNR for clean video transmission.
- Optimized Heat Dissipation: No heatsink required, maintaining a sleek and lightweight design.
- Optional Matching Circular Polarized Antenna Available
Specifications
- Operating Voltage: 6V - 25V (2 - 6S)
- Video Input Impedance: 75 Ohm
- SNR: >63dBm
- Weight: 8.7g
- Dimensions: 37 x 25 x 5.8mm
- Antenna Connector: MMCX
- Video Format: NTSC/PAL
-
Output Power:
- 14dBm (25mW)
- 20dBm (100mW)
- 26dBm (400mW)
- 33dBm+ (2000mW+)
Included
- 1x TBS UNIFY PRO32 DP 5G8 HV Video Transmitter
- Accessories
