Product Details
When power meets precision, magic happens! Elevate your quad's performance with the SpeedyBee 35A 4-in-1 BLHeliS Mini ESC - the heartbeat of every daring aerial stunt.
Key Highlights
⚡ Optimized Power Distribution : Crafted with a 6-layer 2oz PCB, this ESC is engineered to handle the robust demands of 2-4 inch and nimble 5-inch quadcopters. Feel the surge of controlled power.
🛡 Enhanced Protection Galore : With an onboard TVS transient suppression diode, surge voltages don't stand a chance. And with our special touch of a Rubycon 470uF Low-ESR capacitor, your gyro data remains pristine, ensuring smooth flights every time.
🔄 Tailored for Performance : Whether you're looking for continuous 140A output or require optimal current distribution for various freestyle and racing drones, this ESC rises to the occasion.
💡 Japanese TDK Filtering : Incorporating Japanese TDK filtering SMT capacitors, we've pushed the boundaries to enhance your flight experience, making it seamless and ultra-reliable.
Bonus : This ESC doesn't just safeguard against voltage spikes during battery plug-ins; it's resilient during those unexpected prop-blocking crashes too.
Specifications
| ProductName | SpeedyBee 35A BLHeli_S Mini V2 4-in-1 ESC |
| Firmware | BLHeli_S J-H-40 |
| Continuous Current | 35A * 4 |
| Burst Current | 45A(5seconds) |
| ESC Protocol | DSHOT300/600 |
| Power Input | 3-6S LiPo |
| Power Output | VBAT(Battery voltage, used to power the flight controller) |
| Current Sensor | Support (Scale=250 Offset=-500) |
| Mounting | 20 x 20mm ∅3.5mm hole size，compatible with M2 and M3 screws/Silicone grommets. |
| Dimension | 35 * 35 * 5.5mm |
| Weight | 7.2g |
Included
- 1x SpeedyBee 35A 4-in-1 BLHeliS Mini ESC (20x20)
