ARGUS F745 Flight Controller + 40A 4-in-1 ESC Stack (4-6S) - Powerhouse for FPV Drones
Unleash the full potential of your FPV drone with the ARGUS F745 + 40A ESC Stack ! This high-performance combo provides the processing power and robust current handling needed for demanding 5-inch freestyle or racing builds . Built for pilots who require reliability and top-tier performance on 4S to 6S LiPo batteries .
The core of this stack is the F745 Flight Controller , featuring a powerful STM32F745 MCU. This allows for complex filtering, faster loop times, and support for the latest Betaflight or INAV features, resulting in incredibly smooth and locked-in flight characteristics. Paired with the rugged 40A 4-in-1 ESC , this stack delivers ample continuous current (with headroom for peaks) to power demanding motors, ensuring responsive throttle control and durability.
Searching for a reliable F7 flight controller stack , a 40A ESC for 6S , or a complete FPV stack for 5-inch drones ? The ARGUS F745 + 40A stack offers a clean and integrated solution, simplifying your build process while maximizing performance. Get ready to push your flying limits!
Key Features:
- Powerful F745 MCU: Provides high processing power for advanced flight features and smooth performance.
- Robust 40A 4-in-1 ESC: Delivers reliable power for demanding motors on 4S-6S setups. (Likely BLHeli_S or BLHeli_32 firmware - confirm specific firmware if possible )
- 4-6S LiPo Compatibility: Versatile power options for various build types and flight styles.
- Designed for Performance: Ideal for high-speed racing and aggressive freestyle flying.
- Integrated Stack Design: Provides a clean build with easy connection between FC and ESC. (Commonly 30.5x30.5mm or 20x20mm mounting - confirm exact pattern )
Specifications (Typical - Verify with specific product listing):
- Product Name: ARGUS F745 Flight Controller + 40A 4-in-1 ESC Stack
- Flight Controller MCU: STM32F745
- ESC Continuous Current: 40A per channel
- ESC Peak Current: (Typically 45A-55A, varies by model)
- Input Voltage: 4-6S LiPo (Approx. 14.8V - 25.2V)
- Mounting Pattern: (Likely 30.5x30.5mm or 20x20mm - specify if known)
- FC Firmware: Betaflight / INAV (Target specific to board)
- ESC Firmware: BLHeli_S or BLHeli_32 (Target specific to board)
- Weight: 14.4g
- Dimensions: 38 x 45 x 7 mm
What's in the Box:
- 1x ARGUS F745 Flight Controller Board
- 1x ARGUS 40A 4-in-1 ESC Board
- 1x FC to ESC Connection Harness/Cable
- Mounting Hardware (Grommets, Screws, Standoffs)
- 1x Power Lead Pigtail (Likely XT60)
Disclaimer: Please note: Included accessories like connectors, cable lengths, and mounting hardware specifics may vary based on manufacturer supply and batch.
