Happymodel Mobula8 Analog 1-2S 85mm BNF Brushless Whoop

Unleash the Skies: Your All-in-One Solution for Ultimate Flight Experience – Happymodel Mobula8 1-2S 85mm Analog Micro FPV Whoop Drone

If drones were Hollywood actors, our Happymodel Mobula8 would undoubtedly win the Oscar for Best Performance in Aerial Cinematography. It’s time to take flight into the future!

Get ready to launch with…

1. The Sky-Conquering X12 5-in-1 AIO Flight Controller: Built with 2.4G ELRS V2.0 and Openvtx, this maestro of flight guarantees you precise, seamless control even at high altitudes. Your wish is its command!
2. A VTX Powerhouse: Crank it up to 400mw and own the skies like never before. No feat is too high, no distance is too far.
3. Masterclass Motors: Our new RS0802 KV20000 motors aren’t just built for speed – they’re built for a smooth, powerful flight that will leave spectators in awe.
4. A Dazzling Eye in the Sky: The RunCam Nano3, the lightest 1/3 CMOS 800TVL Camera, captures the world from above in breathtaking detail. Don’t just fly; experience the world from a bird’s eye view.
5. Limitless Compatibility: Whether it’s 1S Lipo/LIHV or your favourite 1S 450mah/550mah/650mah battery (not included), our drone is built to adapt and soar.

More Power, Less Fuss

The EX1103 KV11000 motor won’t just send your drone skywards – it’ll leave the competition in the dust. With its innovative 9N12P configuration and a lightweight design, expect unprecedented power that’s as easy to manage as it is impressive.

Flight Controller to Rule the Air

This isn’t your average flight controller. The X12 ELRS V2.1 isn’t just built for flight – it’s designed to conquer the sky. Powered by an MCU:STM32F411CEU6 (100MHZ, 512K FLASH), it’s a high-tech titan capable of managing everything from your BLHeli_S 4in1 ESC to your Betaflight OSD.

The Ultimate Receiver

Our Onboard SPI ExpressLRS 2.4GHz Receiver supports all the channels you need, and then some. With its impressive range and reliable ExpressLRS Firmware, your flight experience is about to become a whole lot smoother.

A Camera That Captures the World

With the Caddx ANT 1200TVL Camera, every flight becomes a cinematic masterpiece. It’s time to unleash your inner filmmaker with stunningly clear footage that will leave your audience breathless.

Get ready to own the skies with the Happymodel Mobula8!

Your package will include your chosen Receiver, Gemfan Hurricane 2023 tri-blade propellers (4CW+4CCW), Screw Driver, and an extra camera canopy.

Why fly when you can soar? Buckle up, and let the Happymodel Mobula8 take you on a flight you’ll never forget.

Specifications

Motor

• Mode: EX1103 KV11000
• Configuration: 9N12P
• Stator Diameter: 11mm
• Stator Length: 3mm
• Shaft Diameter: Φ1.5mm
• Motor Dimension(Dia.*Len): Φ13.5mm*15.5mm
• Weight(g): 3.8g
• No. of Cells(Lipo): 1-2S

Propellers:

• Weight: 0.88g
• Material: PC
• Pitch: 2.3inch
• Props Diameter: 52.17mm
• Center Thickness: 5mm
• Center Hole Diameter: 1.5mm

Flight controller:

• X12 ELRS V2.1 flight controller built-in ELRS 2.4G receiver Target: CRAZYBEEF4SX1280
• X12 Frsky V2.1 flight controller built-in SPI Frsky 2.4G receiver Target: CRAZYBEEF4FR
• X12 Flysky V1.0 flight controller built-in SPI Flysky 2.4G receiver Target: CRAZYBEEF4FS
• X12 PNP V1.1 flight controller without onboard receiver Target: CRAZYBEEF4DX
• MCU:STM32F411CEU6 (100MHZ, 512K FLASH)
• Sensor: ICM20689 or ICM42688P(SPI connection)
• Mount hole size: 25.5mm*25.5mm
• Power supply: 1-2S battery input (DC 2.9V-8.7V)
• Built-in 12A(each) BLHeli_S 4in1 ESC
• Built-in Betaflight OSD(SPI Control)
• Built-in 5.8G OpenVTX 0mw~400mw
• Built-in ExpressLRS 2.4G,Frsky D8/D16,Flysky AFHDS 2A
• Built-in voltage detection
• Built-in current sensor

Onboard 4in1 ESC:

• Power supply: 1-2S LiPo/LiPo HV
• Current: 12A continuous peak 15A (3 seconds)
• Support BLHeliSuite programmable
• Firmware target: Z_H_30
• Default protocol: DSHOT300
• Support Bluejay firmware

Onboard SPI ExpressLRS 2.4GHz Receiver:

• Packet Rate option: 50Hz/150Hz/250Hz/500Hz
• ExpressLRS Firmware version: V2.0
• RF Frequency: 2.4GHz
• Antenna : SMD antenna
• Telemetry output Power: <12dBm
• Receiver protocol: SPI ExpressLRS
• Compatible with ExpressLRS V2.0 TX Module
• ExpressLRS firmware is updated Via Betaflight Firmware not ExpressLRS Configurator.
• To upgrade to ExpressLRS V3.0 update to Betaflight 4.4

Onboard Frsky SPI D8/D16 receiver Version:

• SPI BUS receiver Frsky D8/D16 compatible
• Compatible Non EU transmitter D8/D16 model Channels: 8ch/16ch
• No ground interference ( Transmitter and receiver 1 m from the ground): 200meter Failsafe support

Onboard Flysky SPI receiver Version:

• SPI BUS receiver
• Protocol: AFHDS-2A
• Channels: 14ch(AFHDS-2A)
• No ground interference ( Transmitter and receiver 1 m from the ground): 200 meter Failsafe support

External TBS CRSF Nano Receiver Version:

• Original TBS CROSSFIRE Receiver
• CRSF Protocol
• Official TBS transmitter compatible

PNP Version (without onboard receiver):

• Full UART1 for external Receiver
• Support CRSF/GHOST/SBUS/IBUS/DSMX protocol
• IR1 pad(invert RX1) used for SBUS input

Onboard 5.8g OPENVTX:

• Firmware version: OPENVTX
• SmartAudio v2.1
• PIT Mode support
• RCE Mode support
• Channels: 37ch
• Transmitting Power: 0/RCE/25mw/100mw/400mw
• Power supply: DC 5V
• Current (5v): <650ma (400mw)

Caddx ANT 1200TVL Camera:

• Image Sensor: 1/3″ CMOS Sensor
• Horizontal Resolution: 1200 TVL
• TV System: NTSC or PAL
• IMAGE: 16:9 or 4:3
• Synchronization: Internal
• Electronic Shutter: PAL: 1/50~100,000; NTSC: 1/60~100,000
• S/N Ratio : >52dB (AGC OFF)
• Video Output: CVBS
• Lens: 1.8mm
• Min. Illumination: 0.001Lux@F1.2
• Auto Gain Control: YES
• WDR: Global WDR
• DNR: 3D DNR
• Dimensions: 14*14mm(with bracket to 19*19mm)
• Wide Power Input: DC 3.7-18V
• Weight: 2g (N.W.)

Included

• 1 x Happymodel Mobula8 1-2S 85mm Analog Micro FPV Whoop Drone – Chosen Receiver
• 1 x Gemfan Hurricane 2023 tri-blade propellers (4CW+4CCW)
• 1 x Screw Driver
• 1 x Extra camera canopy
