Product Details
Specification
- Brand Name: FrSky
- Item Name: VANTAC ELRS TX Module
- Dimension: 62.4mm × 30mm×14.5mm (L×W×H)
- Weight: 20g
- Input voltage: 5-12V
- USB port: Type-C
- RGB LED
- Operating Current: 100mA@7.2V
- RF Operating Frequency: 2.4GHz/900MHz/868MHz
- With ELRS firmware
- Packet refresh rate: 25Hz/50Hz/150Hz/250Hz/500Hz (2.4GHz)
- Packet refresh rate: 25Hz/50Hz/100Hz/200Hz (868MHz)
- RF output power: 100mW/250mW/500mW (868MHz)
- RF output power: 10mW/25mW/50mW/100mW/250mW/500mW (2.4GHz)
- Frequency bands: 2.4GHz/868MHz EU
Note
- The 868MHz antenna is not shown in the product photos
Included
- 1 x VANTAC ELRS TX Module
- 1 x Antenna
