Product Details
The SkyRC e680 Universal Charger is easy to use and at the same time offers a variety of features.
All popular battery types such as LiPo/LiIon/LiFe/LiHV/NiMH/NICd/Pb and the system battery of the DJI Mavic are supported by the microprocessor controlled SkyRC e680.
All common loading and unloading modes such as charge, balance charge, fast charge, storage and discharge are mastered. Especially in the Pb program, the charger offers an AGM and cold charging mode. Also DJI Mavic batteries are supported with their own mode.
Key Features
- Excellent performance max. 8A / 80W
- Integrated power supply functionn 13.8V/80W
- 10 battery memory
- TVC Terminal Voltage Control
- Internal balancer with XH connector
- Simplest 4-key operation
- AGM and Pb cold charging modes
- Suitable for LiPo/LiHV/Lilon/LiFe/NiCd/NiMH/Pb and DJI Mavic batteries
Specifications
- Input Voltage AC: 100V -240V
- Input Voltage DC: 11V - 18V
- Max Charge Power: 80W
- Max Discharge Power: 10W
- Charge Current Range: 0.1A - 8.0A
- Discharge Current Range: 0.1A - 2.0A
- Balancer current: max. 300mAh
- Cells: LiPo/LiFe/LiIon/LiHV 1s - 6s
- Cells: NiMH/NiCd 1s - 15s
- Pb Battery Voltage: 2V - 20V
- Weight: 390g
- Dimension: 135x110x60mm
